Cisco QSFP-40G-SR4 40GBASE-SR4 MMF Transceiver Module

Name: Cisco QSFP40GSR4 40GBASESR4 MMF Transceiver Module
Brand: Cisco
Price: 1 USD

Quality Cisco QSFP-40G-SR4 40GBASE-SR4 MMF Transceiver Module for sale

Brand Name : Cisco

Model Number : QSFP-40G-SR4

Certification : CE

Place of Origin : China

Model : QSFP-40G-SR4

Type : 40GBASE-SR4, 4 lanes, 850 nm MMF

Wavelength (nm) : 850

Core Size (microns) : 50.0

Modal Bandwidth (MHz-km) : 500 (OM2), 2000 (OM3), 4700 (OM4)

Cable Distance : 30 m, 100 m, 150 m

Power Consumption (W) : 1.5

Dimensions : 13.5 x 18.4 x 72.4 mm

Condition : Brand new

Warranty : 1 year

Contact Now

QSFP-40G-SR4 Overview

The Cisco QSFP-40G-SR4 is a high-performance QSFP transceiver module designed for enterprise-level applications. This module supports 40 Gigabit Ethernet connectivity over multimode fiber, making it ideal for data-intensive environments. The QSFP-40G-SR4 ensures seamless data transfer with minimal latency, catering to the demands of modern enterprise networks. Its robust design and reliable performance make it an optimal choice for efficient and scalable networking solutions. The cisco qsfp-40g-sr4 enhances network capabilities, offering impressive data throughput and compatibility with various Cisco networking devices.

Cisco QSFP-40G-SR4 40GBASE-SR4 MMF Transceiver Module

Product Features Comparison


Model	QSFP-40G-SR4	QSFP-40G-LR4=	QSFP-100G-SR4-S=
Brand	Cisco	Cisco	Cisco
Data Rate	40Gbps	40Gbps	100Gbps
Cable Reach	150m	10km	100m
Wavelength	850nm	1310nm	850nm
Optical Connectors	MPO	LC	MPO

QSFP-40G-SR4 Specification

Model

QSFP-40G-SR4

Brand

Cisco

Description

Cisco 40GBASE-SR4 QSFP Module for MMF

Dimensions

13.5 x 18.4 x 72.4 mm

Wavelength (nm)

850

Cable Type

MMF

Core Size (microns)

50.0

Modal Bandwidth (MHz-km)

500 (OM2), 2000 (OM3), 4700 (OM4)

Cable Distance

30 m, 100 m, 150 m

Power Consumption (W)

1.5

Pull Tab Color

Beige

Type

40GBASE-SR4, 4 lanes, 850 nm MMF

Transmit Power (dBm)

Max: -1.0 per lane, Min: -7.6 per lane

Receive Power (dBm)

Max: -2.4 per lane, Min: -9.5 per lane

Transmit and Receive Wavelength (nm)

840 to 860

Commercial Temperature

0 to 70°C (32 to 158°F)

Storage Temperature

-40 to 85°C (-40 to 185°F)

Standards

GR-20-CORE, GR-326-CORE, GR-1435-CORE, IEEE 802.3ba (-SR4, -LR4), IEEE 802.3ae (-CSR4), QSFP+ MSA SFF-8436, SFP+ MSA SFF-8431 and -8461, RoHS 6

Safety

Cable jacket of QSFP copper modules is UL E116441 Compliant, QSFP copper cables are ELV Compliant

Cisco QSFP-40G-SR4 40GBASE-SR4 MMF Transceiver Module
